Product Description:
Product Overview
The constant temperature and humidity test chamber is an advanced
environmental test chamber designed for testing the effects of
temperature and humidity on various products. It is also known as a
climatic test chamber or a programmable constant temperature and
humidity test chamber.
Power
The test chamber requires an AC220V power supply with a frequency
of 50Hz and a power consumption ranging from 5.5kw to 13kw,
depending on the model. This ensures stable and reliable operation
of the test chamber.
Lighting Device
The test chamber is equipped with a high-quality LED lighting
device, which is installed on the window of the chamber. This
allows for clear observation and monitoring of the test sample
during the test process.
Temperature Control
The temperature control range of the test chamber is from +20℃ to
-40℃, and it can achieve a temperature decrease rate of 1℃ per
minute. This means that the chamber can quickly and accurately
simulate extreme temperature conditions for testing purposes.
Humidity Control
The test chamber has a humidity fluctuation of ±1.0％RH, ensuring
precise control of the humidity level. It can simulate different
humidity environments to test the effects of humidity on products.
Heating Rate
The heating rate of the test chamber is from -70℃ up to +100℃
within 90 minutes. This means that the chamber can quickly reach
high temperatures for testing purposes. It also has a temperature
accuracy of ±0.5℃, ensuring the reliability of test results.
Overall, the constant temperature and humidity test chamber is an
essential tool for product testing, research, and development. Its
advanced features and precise control make it suitable for a wide
range of industries, including electronics, automotive,
pharmaceuticals, and more.
| Model | IE10A150L | IE10A225L | IE10A408L | IE10A800L | IE10A1000L |
| Temperature range | -70℃ ～ +150℃ |
| Temperature fluctuation | ±0.5℃ |
| Temperature uniformity | ≦2.0℃ |
| Heating rate | from -70℃ up to +100℃ within 90min (When unloaded, the ambient
temperature is +25℃) |
| Temperature decrease rate | from +20℃ down to -70℃ within 90min (When unloaded, the ambient temperature is +25℃) |
| Humidity control range | 20%R.H～98%R.H |
| Humidity deviation | ±3.0％RH(＞75％RH) ±5.0％RH(≤75％RH) |
| Humidity uniformity | ±3.0％RH(unloaded) |
| Humidity fluctuation | ±1.0％RH |
Inner box size: WxHxD(mm) | 500x600x500 | 500x750x600 | 600×850×800 | 1000×1000×800 | 1000×1000×1000 |
Outside box size WxHxD(mm) | 720×1500×1270 | 720×1650×1370 | 820×1750 ×1580 | 1220×1940 ×1620 | 1220×1940 ×1820 |
| Warm-box | ● Outer chamber material: high quality carbon steel plate, surface for
electrostatic color spray treatment. The left side of the box is
φ50mm diameter hole ● Inner chamber material :SUS304# stainless steel plate. ● Insulation material: hard polyurethane foam insulation layer +
glass fiber. |
| Door | For a single door, install a
heating wire in the door frame to prevent condensation in the door
frame at low temperature. |
| Inspection window | The W 300×H 400mm observation
window is installed on the door of the box, and multi-layer hollow
electrothermal coated glass can effectively keep heat and prevent
condensation. |
| Lighting device | 1 LED lighting device, installed
on the window. |
| Sample holder | Stainless steel sample rack 2
layers, height adjustable, bearing weight 30kg/ layer. |
| Refrigeration compressor | France Tecumseh fully closed compressor (2 sets) |
| Coolants | Non-fluorine environmental
refrigerant R404A, in line with environmental regulations, safe and
non-toxic |
| Condenser system | air-cooled |
| Safety protection device | Heater anti-burning
protection; Humidifier anti-burn protection; Heater overcurrent
protection; Humidifier overcurrent protection; Circulating fan
overcurrent overload protection; Compressor high pressure
protection; Compressor overheat protection; Compressor overcurrent
protection; Overvoltage underinverse-phase protection; Circuit
breaker; Leakage protection; Humidifier low water level
protection; Tank low water level warning. |
| Power | AC220V;50Hz;5.5KW | AC380;V50Hz;7KW | AC380;V50Hz;9KW | AC380;V50Hz;11KW | AC380;V50Hz;13KW |
Applications:
Constant Temperature and Humidity Test Chamber
Brand Name: INFINITY
Model Number: IE10A
Place of Origin: MADE IN CHINA
Certification: CE, ISO
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT, PAYPAL, Moneygram and so on
Supply Ability: 200 sets / month
Humidity deviation: ±3.0％RH(＞75％RH) ±5.0％RH(≤75％RH)
Temperature uniformity: ≦2.0℃
Safety protection device:
- Heater Anti-burning Protection
- Humidifier Anti-burn Protection
- Heater Overcurrent Protection
- Humidifier Overcurrent Protection
- Circulating Fan Overcurrent Overload Protection
- Compressor High Pressure Protection
- Compressor Overheat Protection
- Compressor Overcurrent Protection
- Overvoltage Underinverse-phase Protection
- Circuit Breaker
- Leakage Protection
- Humidifier Low Water Level Protection
- Tank Low Water Level Warning
Heating rate: From -70℃ Up To +100℃ Within 90min (When Unloaded,
The Ambient Temperature Is +25℃)
Coolants: Non-fluorine Environmental Refrigerant R404A, In Line
With Environmental Regulations, Safe And Non-toxic
The INFINITY constant temperature and humidity test chamber is a
highly reliable and accurate testing equipment for various
environmental conditions. It is widely used in industries such as
electronics, pharmaceuticals, aerospace, and automotive to test the
performance and durability of products under different temperature
and humidity conditions.
As a programmable constant temperature and humidity test chamber,
the INFINITY IE10A model is designed to provide precise and stable
temperature and humidity control. It is proudly made in China and
has obtained CE and ISO certifications, ensuring its high quality
and safety standards.
The minimum order quantity is only 1 unit, and the price is
negotiable depending on the specific requirements of the customer.
The packaging is carefully designed with clear sheet, sponge, and
wood carton to ensure the safe delivery of the equipment.
The humidity deviation of the chamber is ±3.0％RH(＞75％RH) and
±5.0％RH(≤75％RH), and the temperature uniformity is ≦2.0℃, making it
suitable for conducting precise and accurate tests. It is equipped
with various safety protection devices such as heater and
humidifier anti-burning protection, overcurrent protection, and
high pressure protection for the compressor, ensuring the safety of
the testing process.
The heating rate of the chamber is impressive, capable of reaching
from -70℃ to +100℃ within 90 minutes, even when unloaded and at an
ambient temperature of +25℃. The coolants used in the chamber are
non-fluorine environmental refrigerant R404A, complying with
environmental regulations and being safe and non-toxic.
The INFINITY constant temperature and humidity test chamber is a
reliable and efficient choice for any industry that needs to test
products under different environmental conditions. Its programmable
features, high-quality build, and safety measures make it a
valuable addition to any testing facility.
Customization:
Customized Service for Constant Temperature and Humidity Test
Chamber - INFINITY
Brand Name: INFINITY
Model Number: IE10A
Place of Origin: MADE IN CHINA
Certification: CE ISO
Minimum Order Quantity: 1
Price: Negotiate
Packaging Details: Clear sheet+sponge+wood carton
Delivery Time: 20-30 days after order confirmed
Payment Terms: TT PAYPAL Moneygram and so on
Supply Ability: 200 sets / month
Inspection window: The W 300×H 400mm Observation Window Is
Installed On The Door Of The Box, And Multi-layer Hollow
Electrothermal Coated Glass Can Effectively Keep Heat And Prevent
Condensation.
Coolants: Non-fluorine Environmental Refrigerant R404A, In Line
With Environmental Regulations, Safe And Non-toxic
Lighting device: 1 LED Lighting Device, Installed On The Window.
Refrigeration compressor: France Tecumseh Fully Closed Compressor
Temperature fluctuation: ±0.5℃
Key words: Programmable constant temperature and humidity test
chamber, Environment Test Chamber, Programmable constant
temperature and humidity test chamber for electronics
Packing and Shipping:
Packaging and Shipping
Our constant temperature and humidity test chambers are carefully
packaged to ensure safe delivery to our customers. The chambers are
first wrapped in protective materials to prevent any damage during
transportation. They are then placed in sturdy, custom-made crates
to provide additional protection.
For international shipping, the chambers are securely loaded onto
pallets and then placed in shipping containers. We work with
trusted shipping companies to ensure timely and safe delivery of
our products to our customers all over the world.
Upon arrival, our customers can expect their constant temperature
and humidity test chambers to be in excellent condition and ready
for use.
Contact us for more information on our packaging and shipping
process.
FAQ:
- Q: What is the brand name of this product?
A: The brand name of this product is INFINITY. - Q: What is the model number of this product?
A: The model number of this product is IE10A. - Q: Where is this product made?
A: This product is made in China. - Q: What certifications does this product have?
A: This product is CE and ISO certified. - Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 1.
